UR-3006

Tell us your quantity, interface and intended application.

PRODUCT OVERVIEW

Features

Fast Charging Label Printer With Bluetooth/USB

Support various of intelligent terminal , PDA printing
Support one dimensional code, QR code, image, curves printing
Water proof, dust proof IP54 ( can work even in heavy rainstorm weather)
Resist fall 2.0 concrete
CCC, CE, FCC certificate
Fast charging, finish charging in 3 hours. Support dual charging( adaptor fast charging, USB slow charging to meet client’s demand of using while charging)
Compatible for black mark paper, gap label, sucessive paper
Support button function

TECHNICAL DETAILS

UR-3006 — Printing
Interfaces	USB (Type C)+Bluetooth （WIFI optional)
Print Comand	TSPL /ESC/POS
Print Method	Direct Line Thermal
Print Speed	50mm/s
Print Resolution	203dpi
TPH Life	50km (25% printing density or less) or per dot: 100 million pulses
Memory	ROM: 8192KB / DRAM: 8192KB
Inner Code	ASCII font library (8x16, 12x24, 16x32, 24x48), GBK (16x16), GB1830 (24X24)
Print content	English, Numbers, Various symbols, Chinese characters, Graphics, Curves, Pre-stored icons
One-dimensional code	UPC / UPC-E / CODE39 / EAN-13 / EAN-8 / CODABAR / CODE128 / CODE93 / CODE128 / ITF
Two-dimensional code	QR Code, PDF417
Parameter settings	Printing parameters, Bluetooth parameters, other parameters, etc
Black mark detection	YES
Label detection	YES
Status indication TFT display	Communication mode, Printing, Out of paper, Out of power, Sleep mode, Paper type
Alarm function	Paper out detection, Low battery detection

UR-3006 — Paper
Thermal Paper Types	continuous paper, label paper
Available Rang of Paper Width	20-80mm
Roll Diameter	φ≤43mm
Available Printing Width	72mm (24 Chinese characters/line 48 English characters/line standard 24 dot matrix high font)
Paper Thickness	0.06-0.20 mm

UR-3006 — Electrical
Power Supply	AC 100-240v 5060Hz 0.4A DC 5V 1A
Li-Battery	DC7.4V/ 2000 mAh rechargeable lithium battery
